Shape-shifting smart materials could cut fuel burn
A group of new materials discovered by researchers at Texas A&M University and United Technologies Research Center (UTRC) could significantly improve the efficiency of fuel burn in jet engines, cutting…
A group of new materials discovered by researchers at Texas A&M University and United Technologies Research Center (UTRC) could significantly improve the efficiency of fuel burn in jet engines, cutting the cost of flying.
The ‘smart’ materials could also reduce aeroplane noise over residential areas.
The discovery is based on bringing together two relatively new areas of materials science involving metal alloys, or metals composed of two or more elements.
The first area involves shape-memory alloys, which are materials that can switch from one shape to another with specific triggers – in this case temperature.
The researchers explain: “Picture a straight metal rod that is bent into a corkscrew. By changing the temperature, the corkscrew turns back into a rod and vice versa.”
Professor Ibrahim Karaman, Head of the Department of Materials Science and Engineering at Texas A&M University, commented: “What excites me is that we have just scratched the surface of something new that could not only open a completely new field of scientific research, but also enable new technologies.”
Reducing fuel consumption
There are many potential applications for shape-memory alloys, particularly in the context of extremely hot environments like a jet engine. However, until now, economical high-temperature shape memory alloys (HTSMAs) have only worked at temperatures up to about 400 degrees Celsius. Adding elements like gold or platinum can significantly increase that temperature, but the resulting materials are much too expensive, among other limitations.
Karaman, while working on a NASA project with the United Technologies Research Center, began this research to address a specific problem: controlling the clearance, or space, between turbine blades and the turbine case in a jet engine.
The researchers explain: “A jet engine is most fuel-efficient when the gap between the turbine blades and the case is minimised. However, this clearance has to have a fair margin to deal with peculiar operating conditions. HTSMAs incorporated into the turbine case could allow the maintenance of the minimum clearance across all flight regimes, thereby improving thrust specific fuel consumption.”
Reducing noise
Another important potential application of HTSMAs is the reduction of noise from planes as they come in to an airport. Planes with larger exhaust nozzles are quieter, but less efficient in the air. HTSMAs could automatically change the size of the core exhaust nozzle depending on whether the plane is in flight or is landing. Such a change, triggered by the temperatures associated with these modes of operation, could allow both more efficient operation while in the air and quieter conditions at touchdown.
High entropy alloys
Karaman and his colleagues decided to try increasing the operating temperatures of HTSMAs by applying principles from another new class of materials – high-entropy alloys, which are composed of four or more elements mixed together in roughly equal amounts. The team created materials composed of four or more elements known to form shape-memory alloys (nickel, titanium, hafnium, zirconium and palladium), but purposefully omitted gold or platinum.
“When we mixed these elements in equal proportions we found that the resulting materials could work at temperatures well over 500 degrees C – one worked at 700 degrees C – without gold or platinum. That’s a discovery,” said Karaman.
He added: “It was also unexpected because the literature suggested otherwise.”
New field of research
Karaman said his team has ideas on how the new materials operate at such high temperatures, but do not have solid theories yet. To that end, future work includes trying to understand what is happening at the atomic scale by conducting computer simulations. The researchers also aim to explore ways to improve the materials’ properties even further.
“That’s why I believe this could open a completely new area of research,” he said. “While we will continue our own efforts, we are excited that others will now join us so that together we can push the boundaries of science.”
The research was published in Scripta Materialia journal.
